SPECFICATIONS
| Tripod Model |
T32 LITE |
| Safety Load Capacity* |
20 kg |
| Center Column Diameter |
32mm |
| Number of Sections in Each Leg Tube |
3 |
| Number of Leg Locks per Leg |
2 |
| Leg Tube Diameters |
22mm/25mm/28mm |
| Leg Tube Material |
Carbon Fiber |
| Leg Tube Spread Angle |
23°/0° |
| Leg Tube Graduations |
None |
| Net Weight |
1.3kg (including C32R40 center column) |
| Foot Spike Interface |
M10 |
| Bubble Level |
None |
| Collapsed Length |
46cm (including 40cm center column) |
| Height Range |
42-127cm (excluding the tripod head) |
| Heights for Each Leg Position |
Refer to the working diagram |
| Tripod Model |
T32 LITE PLUS |
| Safety Load Capacity* |
20 kg |
| Center Column Diameter |
32mm |
| Number of Sections in Each Leg Tube |
3 |
| Number of Leg Locks per Leg |
2 |
| Leg Tube Diameters |
22mm/25mm/28mm |
| Leg Tube Material |
Carbon Fiber |
| Leg Tube Spread Angle |
23°/0° |
| Leg Tube Graduations |
None |
| Net Weight |
1.5kg (including
including C32R48 center center column) |
| Foot Spike Interface |
M10 |
| Bubble Level |
None |
| Collapsed Length |
58.5cm (including center column) |
| Height Range |
53-167cm (excluding the tripod head) |
| Heights for Each Leg Position |
Refer to the working diagram |
The T32 Lite tripod can be paired with the other C32 series center columns, such as the C32B and C32G, to achieve the desired height or functionality of the tripod.
WHAT'S IN THE BOX
-
T32Lite/T32Lite Plus Tripod
- C32R Center Center Column/C32K Center Column
- Custom Made Wrench
- Sand Feet
OPTIONS
T32 LITE PLUS+C32G
Safety Load Capacity* refers to the load along the center column axis within the safe range.
Robust Load Capacity
With the thinnest leg section measuring 22mm in diameter, the T32Lite offers stability that exceeds many professional tripods, boasting an impressive load capacity of 20kg.
Efficient Leg Lock Mechanism
The top-positioned leg locks simplify the normal three-step leg lock oprations into a single seamless action. You just loosen it, pull down, and lock it back in place—
all without ever taking your hand off the lock. When retracting, it’s just as simple: loosen it, push up, and lock it—all in the same spot.
Fewer Leg Locks
Unlike most travel tripods which feature 12 to 15 leg locks, the T32Lite is equipped with just six leg locks. This reduction allows for quick deployment and packing, making your shooting process smoother and hesitation-free when adjusting leg sections.
Clean Hands Design
The distance between the leg locks and the feet reduces the chance of getting your hands dirty, ensuring cleanliness throughout your shoot.
Exceptional Grip
The T32Lite’s large horseshoe-shaped rubber feet provide ample contact with the ground, ensuring robust grip even on slick surfaces. Additionally, the wide foot pads absorb more kinetic energy, reducing the impact on the camera and lens upon setting down.
Zero-degree Leg Positioning
When collapsed, the legs stop at a 0° angle rather than colliding with the central column. This innovative design ensures that when the legs are retracted, they stop at a 0° angle without continuing to move inward and potentially collide with the central column, which could cause damage or instability.
The 0° leg stop feature is particularly beneficial in situations where space is limited or when photographers need to position their tripod in tight or awkward spaces, such as against walls or in corners. It allows for greater flexibility in the placement and configuration of the tripod, enabling photographers to adapt to their environment and capture their desired shots. This positioning allows all legs for an invisible effect in panoramic shots with dual-lens cameras.
Compact and Lightweight
This powerful tripod weighs only 1.3kg and folds down to 46cm, easily fitting into a 20-inch carry-on suitcase (varies with internal dimensions of the suitcase).
Versatile Interchangeable Columns and Accessories
Derived from the T32MAX professional tripod platform, the T32Lite delivers exceptional operational feel, stability, and load-bearing capacity. It is compatible with various center columns and professional accessories from the T32MAX platform, providing users with long-term value and versatility. Additionally, the ROGETI RG-1 geared head and its extensive range of components integrate seamlessly, enhancing the system’s synergy and functionality.
Extendable Center Column
The T32Lite’s center column can be extended using the E32 series of extension poles for higher camera positions, enhancing flexibility for higher shooting angles.
Horizontal Column and Vertical Adjustment
Unlike other tripods with horizontal column capabilities, the C32T center column can still move vertically after being positioned laterally, and itself can also connect to extension poles to overcome higher barriers.
Accessories Description
Sandfeet for sandy or muddy terrain
Sandfeet are designed for use on sandy or muddy ground to prevent dirt and debris from entering the tripod legs. They can be directly screwed onto the ends of the T32MAX leg sections.
Wrench Kit for Tripod Adjustment
The Wrench Kit is designed to adjust the opening and closing tension of the T32MAX tripod legs and their central connectors. Its capsule-shaped, nested design makes it easy to store and carry. The kit can be disassembled into four wrenches: two large and two small.
The large wrenches are used to adjust the tension of the three legs on the T32MAX tripod, while the small wrenches are for the C328 tripod. If the legs become loose, the corresponding wrench can be used for tightening.
Wheels(Optional)
Optional wheels are available for cinematography to facilitate smooth, long-distance camera movements and help photographers easily find the perfect shooting angle. The total weight of three tripod wheels and their storage box is only 0.56kg.
